SRFDT Intel Core i3-8145UE Dual-Core 2.20GHz 4MB L3 Cache Socket FCBGA1528 Processor

SRFDT Intel Core i3-8145UE Dual-Core 2.20GHz 4MB L3 Cache Socket FCBGA1528 Processor

Mfg Part No:

SRFDT

Icon Global Part Number(GPN):

1492434246

Availability:In Stock
$253.97 $396.83 You Save: $142.86 (36% )

Looking for a large quantity of SRFDT? Call us at +1 (888) 898-8012 or Request a Quote below and one of our sales representative will get in touch with you very soon.

Request for Quote

Please call at +1 (888) 898-8012 and one of our representative will be happy to assist you with part no SRFDT. Or Request a Quote below:



Technical Specifications

Processor - Package Model: i3-8145UE Socket Type: FCBGA1528
Processor Type Embedded
Processor Family 8th Generation Intel Core i3 Processors
Core Model Type/ProcNo. i3-8145UE
Processor Code Name Whiskey Lake
Manufacturing Technology 14 nm
# of Cores 2
# of Threads 4
Clock Speed 2.20 GHz
L3 Cache Size 4 MB
Thermal Power 15 Watts
Memory Types DDR4-2400
LPDDR3-2133
Memory Channels 2
Maximum Memory Bandwidth 37.5 GB/s
CPU Socket Type FCBGA1528
Max CPU Configuration 1
TJUNCTION 100
Processing Die Size 107 mm2
Processor Graphics Intel UHD Graphics 620
Graphics Base Frequency 350
Graphics Max Dynamic Frequency 1.00 GHz
Graphics Output HDMI/eDP/DP
4K Support Yes, at 60Hz
Max Resolution (HDMI 1.4) 4096 x 2160 @ 24Hz
Max Resolution (DP) 4096 x 2304 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel) 4096 x 2304 @ 60Hz
DirectX Support 12
OpenGL Support 4.5
Intel Quick Sync Video Yes
# of Displays Supported 3
Embedded Options Available No
PCI Express 3.0
PCI Express Configurations 1 x4
Max # of PCI Express Lanes 16
Advanced Technologies Enhanced Intel SpeedStep Technology
Idle States
Instruction Set 64-bit
Intel 64
Intel Hyper-Threading Technology
Intel Optane Memory Supported
Intel Turbo Boost Max Technology 3.0
Intel Turbo Boost Technology 2.0
Intel Virtualization Technology (VT-x)
Intel Virtualization Technology for Directed I/O (VT-d)
Intel VT-x with Extended Page Tables (EPT)
Thermal Monitoring Technologies
Security & Reliability Execute Disable Bit
Intel AES New Instructions
Intel Boot Guard
Intel OS Guard
Intel Software Guard Extensions (Intel SGX)
Product Condition OEM
Standard Warranty 21 days

General Information

OEM CPUs.
  • The CPU you are ordering, if it is designated as OEM it can be NEW or Refurbished.
  • Depending on how old the CPU is and how long it has been out of production, the CPU condition may be new, pull, pre-owned, or like-new condition. The older the cpu is the more likely it is out of production. In that case these pre-owned, pulls are the only ones available.
  • ALL OEM Cpus are tested before shipping and carry a 21 day warranty for replacement only. There are NO cancellations or returns accepted for these parts.
  • Please check your system requirements carefully before ordering CPU's.
  • If you are going to use the CPU in a dual-cpu SERVER application or machine then YOU MUST match the SL code for the new CPU with your existing CPU . Please call us if you need help.
  • SL codes - All INTEL cpu's are also designated by a Step code or SLcode. This is a 5 digit alpha-numberic code on the cpu itself. Your particular cpu may have many SL codes (think of them as versions of cpus made). In order to run dual cpus in one machine the SL codes must match
  • If you have a brand name computer (eg HP, DELL, IBM you must provide us with a HeatSink part number or we will ship you a generic heatsink if you order one from us.)
  • SRFDT Intel Core i3-8145UE Dual-Core 2.20GHz 4MB L3 Cache Socket FCBGA1528 Processor Refurbished
